Kevlar Honeycomb | Aramid Honeycomb

Core Material: Aramid Paper Honeycomb (Industrial Grade, Aerospace Grade)

Our kevlar honeycomb core and aramid fiber honeycomb are ultra-lightweight, high-strength materials made by impregnating high-performance meta-aramid or para-aramid paper with phenolic resin. Designed for advanced applications, these aramid kevlar honeycomb products offer exceptional flame retardancy, corrosion resistance, dielectric properties, fatigue resistance, and impact resistance.

Ideal for aerospace, military protection, shipbuilding, rail transportation, and radar radomes.

Key Features

• Lightweight & High Strength: Exceptional weight-to-strength ratio for demanding structural applications.
• Flame Retardant & Corrosion Resistant: Superior fire performance and chemical resistance.
• Durable & Fatigue Resistant: Maintains performance under repeated stress and load.
• Impact Resistant & Easy to Process: Can be molded or cut into complex shapes without losing integrity.
• Wide Range of Applications: Aerospace, racing vehicles, containerized special vehicles, radomes, and aircraft flooring.

Types of Aramid Honeycomb

• Meta-Aramid Honeycomb: Made from high-performance meta-aramid paper; used in aerospace and industrial-grade applications. Supports honeycomb kevlar hood and other precision components.

  Cell size	Length	mm	1.83              2.29            2.75            3.67         4.5        5.5
  	Diameter	Inch	1/8              5/32            3/16            1/4         5/16        3/8
  		mm	3.2              4.0            4.8            6.4         8.0        9.5
  Density		Lb/ft³	1.8           2.0          3.0          4.0          5.0          6.0          8.0          9.0
  		Kg/m³	29           32          48         64          80          96          128          144
  Standard size		Inch	48*96          51*102
  		mm	1220*2440          1300*2600


• Para-Aramid Honeycomb: Superior weight, strength, and fatigue performance; commonly used in load-bearing structures like aircraft flooring.

  Cell size	Length	mm	1.83              2.75
  	Diameter	Inch	1/8              3/16
  		mm	3.2              4.8
  Density		Lb/ft³	2.5           3.0          4.0          6.0
  		Kg/m³	40           48          64         96
  Standard size		Inch	48*96          51*102
  		mm	1220*2440          1300*2600

Why Choose Kevlar Honeycomb?

• Combines the benefits of kevlar honeycomb core, aramid fiber honeycomb, and kevlar nomex honeycomb.
• Lightweight alternative to metals and traditional composites.
• Excellent dielectric properties make it suitable for radar radomes and electronic housings.
• Strong, durable, and easy to integrate into advanced composite structures.

Market Insights

• Aramid Honeycomb Core Material Market: Growing demand in aerospace, defense, automotive, and industrial sectors.
• Honeycomb Kevlar vs Carbon Fiber: Offers superior flame retardancy, dielectric performance, impact resistance, and cost-effectiveness in many applications.
